Toggle and spring fixing KD/KDH

The cavity fixing for different board thicknesses and large usage lengths

With the fischer toggle and spring fixing KD/KDH different fittings such as pictures, lamps and shelves can be fixed in gypsum plasterboard and gypsum fibreboards, chipboard and cavity floor slabs made from bricks and concrete. The long threaded rod allows use in different panel thicknesses and fitting thicknesses. Also available with head (KD 3+4), nut with washer (KD 5+6+8) or round hook (KDH 3+4+5+6+8). As a result the fischer KD/KDH can be used particularly flexibly. The plugs are inserted in the pre-position installation into the drill hole and automatically fold out behind the panel. A special installation tool is not needed and this allows comfortable and quick installation.

To all Variants
Advantages
  • The long threaded rod allows use in different panel thicknesses and fitting thicknesses.
  • The folding elements open automatically and facilitate easy installation.
  • No special installation tool necessary
Variant
Drill hole diameter
d0
Max. panel thickness
dp
Min. cavity depth
a
Anchor length
l
Thread
Ø x length
VH M4 K NV Art.-No. 015026
10 [mm]
69 [mm]
—
100 [mm]
M 4 x 75 [mm]

Attributes

Drill hole diameter
d0
 10 [mm]
Max. panel thickness
dp
 69 [mm]
Min. cavity depth —
Anchor length
l
 100 [mm]
Thread
Ø x length
 M 4 x 75 [mm]
Card contents —
Cartons of —
Amount —
GTIN (EAN Code) 8413159150267
To product variant
VVR M4 K NV Art.-No. 015025
10 [mm]
25 [mm]
—
100 [mm]
M 4 x 100 [mm]

Attributes

Drill hole diameter
d0
 10 [mm]
Max. panel thickness
dp
 25 [mm]
Min. cavity depth —
Anchor length
l
 100 [mm]
Thread
Ø x length
 M 4 x 100 [mm]
Card contents —
Cartons of —
Amount —
GTIN (EAN Code) 8413159150250
To product variant
KDH 4 K NV Art.-No. 084342
14 [mm]
25 [mm]
34 [mm]
95 [mm]
M 4 x 95 [mm]

Attributes

Drill hole diameter
d0
 14 [mm]
Max. panel thickness
dp
 25 [mm]
Min. cavity depth
a
 34 [mm]
Anchor length
l
 95 [mm]
Thread
Ø x length
 M 4 x 95 [mm]
Card contents 2 x KDH 4
Cartons of —
Amount 2 Unit(s)
GTIN (EAN Code) 8590369843421
To product variant
KD 4 K NV Art.-No. 084341
14 [mm]
69 [mm]
34 [mm]
105 [mm]
M 4 x 100 [mm]

Attributes

Drill hole diameter
d0
 14 [mm]
Max. panel thickness
dp
 69 [mm]
Min. cavity depth
a
 34 [mm]
Anchor length
l
 105 [mm]
Thread
Ø x length
 M 4 x 100 [mm]
Card contents 2 x KD 4
Cartons of —
Amount 2 Unit(s)
GTIN (EAN Code) 8590369843414
To product variant
KDH 3 K NV Art.-No. 045475
12 [mm]
51 [mm]
27 [mm]
105 [mm]
M 3 x 80 [mm]

Attributes

Drill hole diameter
d0
 12 [mm]
Max. panel thickness
dp
 51 [mm]
Min. cavity depth
a
 27 [mm]
Anchor length
l
 105 [mm]
Thread
Ø x length
 M 3 x 80 [mm]
Card contents 2 x KDH 3
Cartons of —
Amount —
GTIN (EAN Code) 8590369454757
To product variant
KD 3 K NV Art.-No. 045474
12 [mm]
65 [mm]
27 [mm]
95 [mm]
M 3 x 90 [mm]

Attributes

Drill hole diameter
d0
 12 [mm]
Max. panel thickness
dp
 65 [mm]
Min. cavity depth
a
 27 [mm]
Anchor length
l
 95 [mm]
Thread
Ø x length
 M 3 x 90 [mm]
Card contents 2 x KD 3
Cartons of —
Amount 2 Unit(s)
GTIN (EAN Code) 8590369454740
To product variant
KDH 4 K NV Art.-No. 014885
14 [mm]
25 [mm]
34 [mm]
95 [mm]
M 4 x 95 [mm]

Attributes

Drill hole diameter
d0
 14 [mm]
Max. panel thickness
dp
 25 [mm]
Min. cavity depth
a
 34 [mm]
Anchor length
l
 95 [mm]
Thread
Ø x length
 M 4 x 95 [mm]
Card contents 2 x KDH 4
Cartons of —
Amount —
GTIN (EAN Code) 8413159148851
To product variant
KDH 8 Art.-No. 080179
20 [mm]
55 [mm]
75 [mm]
130 [mm]
M 8 x 100 [mm]

Attributes

Drill hole diameter
d0
 20 [mm]
Max. panel thickness
dp
 55 [mm]
Min. cavity depth
a
 75 [mm]
Anchor length
l
 130 [mm]
Thread
Ø x length
 M 8 x 100 [mm]
Card contents —
Cartons of —
Amount 20 Unit(s)
GTIN (EAN Code) 4006209801796
To product variant
KDH 6 Art.-No. 080186
16 [mm]
60 [mm]
70 [mm]
130 [mm]
M 6 x 100 [mm]

Attributes

Drill hole diameter
d0
 16 [mm]
Max. panel thickness
dp
 60 [mm]
Min. cavity depth
a
 70 [mm]
Anchor length
l
 130 [mm]
Thread
Ø x length
 M 6 x 100 [mm]
Card contents —
Cartons of —
Amount 20 Unit(s)
GTIN (EAN Code) 4006209801864
To product variant
KDH 5 Art.-No. 080188
16 [mm]
60 [mm]
70 [mm]
130 [mm]
M 5 x 90 [mm]

Attributes

Drill hole diameter
d0
 16 [mm]
Max. panel thickness
dp
 60 [mm]
Min. cavity depth
a
 70 [mm]
Anchor length
l
 130 [mm]
Thread
Ø x length
 M 5 x 90 [mm]
Card contents —
Cartons of —
Amount 20 Unit(s)
GTIN (EAN Code) 4006209801888
To product variant
KDH 4 Art.-No. 080184
14 [mm]
35 [mm]
34 [mm]
95 [mm]
M 4 x 70 [mm]

Attributes

Drill hole diameter
d0
 14 [mm]
Max. panel thickness
dp
 35 [mm]
Min. cavity depth
a
 34 [mm]
Anchor length
l
 95 [mm]
Thread
Ø x length
 M 4 x 70 [mm]
Card contents —
Cartons of —
Amount 25 Unit(s)
GTIN (EAN Code) 4006209801840
To product variant
